SPW300 windows – can be manufactured in single, double, inward and outward opening configurations and are constructed using thermally broken polyamide aluminium. This high performance window system is ideal for commercial projects and includes fixed lights, tophung, sidehung, tilt-turn, pivot (horizontal and vertical) and overswing windows.
If you would like more information or to place your order please give us a call on 01484 650000 or fill out the contact form.
- Weather Rating tested to BS 6375-1:2009 achieving 600Pa air permeability, 600Pa water tightness and 2000 to 2400Pa wind resistance depending on configuration.
- Able to receive glass and infill panels from 4 to 32mm thick depending on configuration.
- Available in two finishes:
- Polyester powder coating to BS EN 1220: 2004 Part 1 – painted in single or dual colour and surface finish at 40 microns, or enhanced to 60 microns for marine environments.
- Anodised and Anolok finishes are to BS3897: 1991 to a minimum of 25 microns (AA25), supplied in either satin or polished finish.
Casement Open Out
| Typical* Sizes | |||
|---|---|---|---|
| Width(mm) | Height(mm) | ||
| Top Hung Open Out | 1500 | X | 1500 |
| Side Hung Open Out | 900 | X | 1500 |
| Security |
|---|
| Tested to BS7950, Security hardware required |
| Glazing | |||
|---|---|---|---|
| Thickness | 4mm | to | 32mm |
| Average U Values |
|---|
| Differing window + glass configurations produce differing U-values – Please consult our technical department |
| Weather rating (BS6375) | |
|---|---|
| Air Permability | 600 Pa |
| Water Tightness | 600 Pa |
| Wind Resistance | 2000 Pa |
The full data sheet can be found here.
Tilt and Turn
| Typical* Sizes | |||
|---|---|---|---|
| Width(mm) | Height(mm) | ||
| Tilt/Turn | 1500 | X | 1500 |
| Tilt/Turn Heavy Duty | 1500 | X | 2200 |
* For guidance only
| Security |
|---|
| Tested to BS7950, Security hardware required |
| Glazing | |||
|---|---|---|---|
| Thickness | 4mm | to | 32mm |
| Average U Values | |||
|---|---|---|---|
| 1200 x 1200 | 1500 x 1500 | ||
| Fixed | 1.61W/m2K | 1.53W/m2K | |
| Vent | 1.86W/m2K | 1.74W/m2K | |
| Weather Rating | |
|---|---|
| BS6375 Part 1 | |
| Air Permeability | 600 Pa/Class C |
| Water Tightness | 600 Pa |
| Wind Resistance | 2400 Pa |
The full data sheet can be found here.
